S Cleat
S Cleat
Description
S Cleats are manufactured using galvanized steel. Available in the following gauges: 24, 26, 28 & 30.
Applications
Used to secure two pieces of duct together.
Features & Benefits
– Fully automated process ensures consistency
– Union Made
Part Number Table
| 24 GAUGE |
| Part Number | Description | UOM | Ctn.Qty |
| 5CSF12024 | (M) 120″ S CLEAT 24GA | LT | 10 |
| 26 GAUGE |
| Part Number | Description | UOM | Ctn.Qty |
| 5CSF6026 | 60″ S CLEAT 26GA | LT | 20 |
| 5CSF12026 | 120″ S CLEAT 26GA | LT | 10 |
| 28 GAUGE |
| Part Number | Description | UOM | Ctn.Qty |
| 5CDR0828 | 8″ D CLEAT 28GA RD | LT | 50 |
| 5CDR1028 | (M) 10″ D CLEAT 28GA RD | LT | 50 |
| 5CDR1228 | (M) 12″ D CLEAT 28GA RD | LT | 50 |
| 5CSF6028 | 60″ S CLEAT 28GA | LT | 20 |
| 30 GAUGE |
| Part Number | Description | UOM | Ctn.Qty |
| 5CDR0830 | (M) 8″ D CLEAT 30GA RD | LT | 50 |
| 5CDR1030 | (M) 10″ D CLEAT 30GA RD | LT | 200 |
| 5CSF6030 | 60″ S CLEAT 30GA | LT | 20 |
